Main Parameter
| Model Number | 500 | 630 | |
Dia. Of Single Wire(mm) | Copper | 1.5-5.0 | |
Aluminum | 1.8-5.0 | ||
Max.Section Square(mm2) | Cu | 500 | |
Al | 630 | ||
Max Linear Speed(m/min) | 7.32-55.29 | 7.62-57.93 | |
Pay-off In Cage | PND500 | ||
Stranding Pitch(mm) | 45-1105 | 56-1259 | |
Take-up Bobbins(mm) | PN1600-PN2500 | ||
Capstan(mm) | 2000mm | ||
Features
1.All Cages, Pre-Spiraling Heads, Taping Head, Capstan & Takeup are separately driven.
2.All bobbins can be loaded/unloaded simultaneously by automatic loading equipment, thereby reducing loading/unloading time to Max. 30 minutes.
3.Lay is fed in MMI (Operator touch screen) instead of Gearbox. Any lay value in the range can be set & achieved that ensure easy operation.
4.In Power failure situation, the machine comes to a controlled stop by emergency braking system, enabling the bobbin is held by spring pressure with a secondary positive lock. The release of bobbin is by externally plugged pneumatic compressed Air.
5.Constant Bobbin back tension achieved by Electronic pneumatic valve & Single bobbin rotation is electronically sensed for maintaining consistent tension by positive motor control system or passive mechanical equipment.
6.Multiple bobbin size available(400,500,630.etc)
7.Mutiple host with mutiple cage number((6.12.18.24.30)) optional
